Combat Camo 250/300 2017

£6,295.00

Model Description


The two-stroke machine has been designed to create an incredibly strong and balanced overall package. The ultra compact engine offers amazing torque throughout, thanks to the boundary breaking electronic system, with the ECU managing and controlling the performance of the engine in all situations. The ECU adjusts the fuel injection and ignition settings in each and every gear to provide exceptionally smooth power delivery to match all terrain / conditions. Performance is maintained in all circumstances due to the high air intake, and specially designed radiator that works seamlessly in conjunction with the electronic water pump and fan.

The superb engine characteristics are matched by a chassis package to suit. The steel multi-tubular main section provides flexibility to give the rider real time feedback whilst the aluminium sub-sections at the front and rear provide the required rigidity to withstand the rigors of all competitions. The central low mounted fuel tank means that the suspension action is unaffected by fuel load. The sleek and narrow lines of the specially designed plastic bodywork that incorporates further new technology, twin outlet silencer and flush fitting fuel cap finish off what can only be described as truly the next generation of trials bike.

Model Specification


  • Engine

    ENGINE

    2 stroke engine, EFI

    POWER

    25 HP / 9200 rpm | 31 HP / 9200rpm

    TORQUE

    4,0 Kg.m / 4500 rpm | 4.9 Kg.m / 4500 rpm

    GEARBOX

    6 Speed gear, 4 gear trials developed, each one ECU controlled

    ECU ENGINE CONTROL UNIT

    Vertigo design, controlling: gear position, engine temp, humidity, pressure, gas pump, water pump, radiator function, electr timming

    ENGINE CONTROL SENSORS

    Integrated injection driver

  • Transmission

    CLUTCH

    Oil wet multidisc

  • Other

    RADIATOR

    Vertigo design, adapted to frame shape

    POWERBOX ECU

    Vertigo design, controls all the electircal power, protects all the components from short circuit

    AIRBOX

    1,1l capacity upper position airbox

    FUELTANK

    2,71l capacity, low and centre of gravity position

  • Dimensions

    WEIGHT

    69kg

    SWING ARM

    Cast aluminum pivoting points arm, 2 pivot swivel points swing arm

  • Frame

    FRAME

  • Suspension

    FRONT SUSPENSION

    Tech Alu Black

    REAR SUSPENSION

    Mono shock/swing arm, Vertigo design swing arm combined with REIGER monoshock with rebound adjustment
