STEP INTO THE BIG LEAGUES
2027 KTM Motocross
MY27 KTM 85 SX 17/14
STEP INTO THE BIG LEAGUES
- •The last step awaits. The KTM 85 SX 17/14 is ready to raise the speed for you. Developed on track and at an international level, the KTM 85 SX 17/14 boasts significantly enhanced handling, searing power delivery and proven READY TO RACE DNA through its components and pedigree. You spoke, we listened. We developed. Now continue the journey. Fast.
Price Promise
We guarantee competitive pricing across our full range of new and used bikes.
Certified Dealer
Officially authorised and trusted to supply and support leading motorcycle brands.
Extended Warranty
Added peace of mind with comprehensive warranty options available.
4.8 Google Rating
Highly rated by our customers for service, expertise, and reliability.
Tech Specs
ENGINE TECHNICAL DATA
Engine
Engine Type
Single cylinder, 2-stroke
Displacement
84.9 cc
Bore / Stroke
47 / 48.95 mm
Starter
Kickstarter
Cooling
Liquid cooling (0.8 L)
Carburettor
Keihin PWK 28
Control
Exhaust flap (rpm dependent)
Ignition
HIDRIA digital
Lubrication
Mixture lubrication 1:40
Transmission
Gears
6
Clutch
Wet multi-disc clutch, Formula hydraulics
Transmission Oil
Motorex Topspeed 4T 15W50
Chassis
Frame
Central double-cradle-type frame
Subframe
Aluminium / Polyamide Glass Fiber
Handlebar
Tapered aluminium Ø 28 / 22 mm
Suspension
Front Suspension
XACT 43 WP Upside-Down fork, Ø 43 mm
Rear Suspension
XACT WP PDS Monoshock
Suspension Travel Front / Rear
278 / 289 mm
Wheels, Tyres & Brakes
Front / Rear Rims
- Small wheel: 1.40 × 17" / 1.60 × 14" — Aluminium
- Large wheel: 1.60 × 19" / 1.85 × 16" — Aluminium
Front / Rear Tyres
- Small wheel: 70/100 × 17" / 90/100 × 14"
- Large wheel: 70/100 × 19" / 90/100 × 16"
Front Brake
Disc brake Ø 240 mm
Rear Brake
Disc brake Ø 220 mm
Dimensions & Weight
Values in brackets refer to the large wheel variant.
Wheelbase
1,282 mm ± 10 mm
Ground Clearance
308 mm (large wheel: 333 mm)
Seat Height
845 mm (large wheel: 871 mm)
Tank Capacity (approx.)
5.4 L
Weight (ready to race, without fuel)
approx. 68 kg (large wheel: approx. 69 kg)
